Making virtual art physical - Part 1
Time for my first actual post! Let me tell you about my latest hobby project. This is part 1 in a two-part series - strap in!
Drarwing
About two months ago, my colleague Berry shared his latest project:
Drarwing. I wholeheartedly suggest reading the blog post (and the
subsequent post about how he turned it into a web-hosted tool
here), but in short, Drarwing takes a photo, and using a
generative approach, turns it into a painting. It semi-randomly places brushstrokes on the canvas, and checks whether the
resulting image is more like the original than before. If it is, the brushtroke is kept, otherwise it tries again with
a different random stroke. That results in beautiful painting-like images, but what is really cool is watching the
process unfold:
The plan
Unfortunately, Berry was a little preoccupied with becoming a father (priorities, right?), but he graciously said “The code is open source so feel free to run with those ideas yourself!”. And with that, my new hobby project was born. There are only a few small things that need to be done:
- The application needs to continue with the next photo once the previous is done
- It needs to be run on some hardware small enough to fit in a frame, so the code needs to be fast
- There should be a convenient way to get the photos on the device, without physical interaction
- We need to create a frame that has a display, contains all the components and looks like a painting
Piece of cake.
Modifying the code
Lets start with the part that has the lowest barrier of entry (I’m slowly coming to grasps with how my brain works): Modify the code. I forked Berry’s repository, and started experimenting. Naturally, the version I created is available as open source, like the original. Read on to see the changes I made.
Modifying the code to draw the next picture once the previous is done was the first step, and it was very straight forward - the joys of working with code made by an experienced software engineer. To follow some best practices from the world of rendering and graphical user interfaces, I created a separate rendering thread to have control over the framerate, decoupled from the speed of the drawing. I also introduced some parameters to control how fast the drawing is done and how long the result is shown before starting the next drawing. Finally, I introduced some debugging functionality that allow showing the “difference image” (the difference between the current painting and the target image) and the target image itself.
FASTER!
The speed of the drawing was the next step. Since we’ll be using low-powered hardware and we need to add some complexity (more below), I wanted to find all the performance I could. That calls for something I’m a big advocate of:
🌟PROFILING🌟
(this might be a future blog topic). It immediately became clear that most of the runtime was spent copying objects.
Some further investigation allowed me to cut this time down significantly, by decreasing the number of deepcopy()s
required, and using numpys built-in copy mechanism for the ndarrays containing the image data instead.
These changes were also merged back to the original
Drarwing application, allowing some more advanced features there too.
A further speed improvement is to work with a downscaled difference image (1/4th of the actual image size). The brush strokes are sufficiently large that using a higher resolution does not improve the result.
How different are colours?
All this performance improvement means we now have the margin to use some more advanced scoring metrics. A scoring metric is used to determine how good a randomly placed brushstroke really is. This is determined by looping through all the pixels, and comparing how that pixel looks in the drawing versus the original image. This is then added up for the entire image to determine how much the drawing looks like the original.
In the original Drarwing, the difference between two pixels is simply taken as the absolute difference between their grayscale values. This works fine, because the canvas starts as white, meaning that the entire picture will get covered with some color closer to the target anyway.
However, in this version the base canvas is not white, but it’s the previous drawing. That causes some issues, as two colors that look completely similar in grayscale, may look completely different to us humans. This can lead to large areas of the image having the wrong color.
To fix this, we can use something called the ΔE metric. This metric works in the CIELAB color space, which is specifically designed to represent how colors are perceived by humans. We can then use the CIE1976 calculation to determine the difference between two colors as follows:
$$ \Delta E = \sqrt{(L_{2}-L_{1})^{2}+(a_{2}-a_{1})^{2}+(b_{2}-b_{1})^{2}} $$
(Of course, since we’re using Python, there’s a package for that). Note that there are more advanced implementations of the ΔE metric, but these have only small improvements that don’t have a lot of impact, while they do add a lot of performance costs.
I want to see some footage
In the end, the result looks like this. Note the rendering speed (on a high-power desktop), the reasonably good coverage of the previous painting - most of the time - and in the second half of the video the switching between original, target and difference images:
Scale it down
Of course, we can’t keep running this application on a high-performance desktop machine. Ideally, the entire device will be self-contained, only needing power from the outside. So, we need a small computer. In today’s world, that means a Raspberry Pi. And as smaller (and especially flatter) is better in this case, I decided to go with a Raspberry Pi Zero 2 W. A bonus here is that this version has Wi-Fi included, which will be very convenient later on.
Keeping control
Raspberry Pis come with a limitation though: It does not have a power button. This is fine for devices used as an always-on server, or when running the device interactively. For this use-case however, it means it can’t be shutdown properly. That leaves just pulling the power cable, which can lead to SD card corruption and a bricked Raspberry installation. Not ideal.
So we need a solution. The Pi supports a “halt state”, in which it is in a sort of deep-sleep state (and won’t corrupt the storage when powered off). While in this state, if you short the GPIO3 pin to ground, it will wake back up.
So the solution is simple: We add a button between GPIO3 and GND. This button can be used to power the Pi back up, and by adding a simple script that listens on this pin while the Pi is turned on, it can be used to put the Pi into the halt state.
A second button is added to trigger Drarwing to start rendering the next image right away, which seemed like a fun additional functionality.
Pushing pictures
The “self-contained” part of the frame also means I want to have a clean and simple way to update the photos that are
shown on the device. This is where the Wi-Fi functionality comes in. As the Pi is connected to the internet, it was
fairly trivial
to add a sync with a Google Drive folder. It uses rclone to create a clone of a folder in my Google Drive, meaning
that it’s really easy to add or remove photos from the frame.
Time for a break
As I started writing, I realized I have a lot to say about this project. We haven’t even started on the exciting part! Since the software side is done now, I’m going to leave the hardware part for a next post. To be continued.
